Pump control in a home pumping station
The simplest way to control the pump is to turn it on and off. You can of course do it manually, but it works much more efficiently when the pump is controlled automatically. For this purpose, we can use the control float built into the pump, which, when raised up with the rising liquid level in the tank, will turn on the pump, and when lowered down with the falling liquid level, it will turn off the pump. A simple and effective solution. Sufficient for most home pumping stations. We don't have to worry about when the pump will turn on and off because this is determined by the properly adjusted length of the float switch. Can we now sleep soundly? Unfortunately no, the reason is unforeseen situations causing...
Alarm in the pumping station
Each pump operating in the pumping station, regardless of type, lifting parameters and hydraulic solution (Vortex, shredder, screw, etc.) is susceptible to damage due to overheating, leakage or blocked rotor. In the case of a pump that operates autonomously, the user does not receive any feedback about its operation. The solution to this is...
Control and alarm automation
Control and alarm automation in the form of control cabinets EM4IS ASAL, ASPP or controller 3XAL PRO In addition to managing the pump's operation, it also offers extensive messages and information about the pump's operating status and the general condition of the pumping station. Depending on the type and version of the control, we may receive information about pump damage, overflow in the tank, exceeded power supply parameters or imminent service.
ASAL
A simple and effective control and alarm cabinet that protects the pump with a built-in float against power failure, pump failure and exceeding the alarm level in the tank,
ASPP
Control cabinet enabling manual and automatic operation of the pump, protection against overload and power supply fluctuations, signaling a failure with a beacon with a light and siren, and in the version with a GSM module, sending SMS messages to the user's telephone number.
3XAL PRO
The extensive control and protection capabilities of the controller, as well as the ability to adapt it to many pump models, make it a real combine for pumping station control. In addition to many reports on the status of pumps and power supply, we can also check the last 10 saved errors from the device's operation history. Models 3XAL PRO TUYA also have the function of remote control and notifying the user about failures using the Android application on the TUYA WI-FI smartphone.
Control defects
Each of the mentioned devices has its advantages and disadvantages. One of their biggest disadvantages is, of course, their cost. Control cabinets, due to their modular structure and ease of servicing, and, above all, the housing's resistance to external weather conditions (rain, frost, snow, sun, etc.), cost much more than a controller that is intended for internal installation in a building.
Product price and the price of peace of mind
If trouble-free operation of the pumping station is important to us and we do not want to be flooded with sewage at the least appropriate moment, the use of control and alarm automation is simply necessary. Only properly selected automation will alert us in time about pump failure or power failure, then the price of the product is equivalent to the price of peace of mind. The costs of troubleshooting are usually many times higher than the initial cost of installing the alarm device.
Which product should I choose?
Dear customer, contact me, spend 10 minutes to talk and I will present you the best solution, one that will meet your expectations and at the same time you will not overpay for a useless gadget in your home or company.
