AKG 50-32Z flange-fed adapter DN50 x 1cut "GZ for sewage pumps

Adapter / adapter / connector for sewage pumps and hinged feet.

Collar adapter EM4IS AKG 50-32Z It enables the connection of collars with different nominal diameters DN and various PN pressure with 5/4 inches internal thread (1¼"). Possible combinations:

Collar DN Inch tubular thread

1. DN32 PN6 |
2. DN32 PN16 |
3. DN40 PN6 |
4. DN40 PN16 |    G1¼"
5. DN50 PN6 |
6. DN50 PN16 |
7. DN65 PN6 |

The kit includes:

1. AKG 50-32Z adapter (powder painted gray cast iron) - 1 pc.
2. Universal AKG 50-32U (DN32/DN50/DN65 PN6) gasket (EPDM) - 1 pc.
3. M12x50 DIN 933 screws (stainless steel 304) - 4 pcs.
4. M12 DIN 934 caps (stainless steel 304) - 4 pcs
5. Fi13 DIN 125 pads (stainless steel 304) - 8 pcs
6. M12 DIN 127 elastic pads (stainless steel 304) - 4 pcs.


Industrial pattern reserved!
