GZ clutching foot threaded for independent configuration

The coupling foot is also often called a clutch knee for professional assembly of submersible pumps in pumping stations. Thanks to the coupling foot, the pump with a screwed clip is lowered to the bottom of the tank or pulled out after two tubular guides without having to enter the tank. Even in the case of stuck pumping stations, when the DNA cannot be seen, the pump will accurately settle on the foot and satisfied. The sealing o-ring between the hook and the foot ensures effective adhesion of the planes and the tightness of the connection and, as a result, minimizing losses in the pump efficiency.

The GZ foot for independent configuration allows you to match the set perfectly to expectations. All hooks and feet of the GZ series can be used interchangeably, also due to the diameter of the connections, e.g. GZ32-ZP + GZH50. However, it is not recommended to use a larger flight through the hook than the diameter of the foot, due to the possibility of clogging the discharge pipe.

Inlet (pump hook) to choose from the list:

• Simple GZ-ZP with external thread: G1-1/4 ", G1-1/2" or G2 ",
• Knee GZ-ZM with external thread G1-1/2 "or G2",
• Knee GZ-ZF with internal thread G1-1/2 "or G2",

Outlet (pipeline connection) to choose from the list:

• GZP50W simple with internal thread G2 ",
• GZP50 simple with G2 external thread ",
• High knee GZH50 with G2 external thread ",

• Low knee GZL50 with G2 outer thread ".

The kit includes:

1. Inlet - pump hook.
2. Departure - coupling foot.
3. Sealing o-ring.
4. A set of stainless steel: screws, pads and nuts.
5. The upper bracket of the guides.
6. Mounting pins (anchors and fischery).
7. User manual.

Material execution:

1. Crushing foot - gray cast iron -painted iron.
2. Pump hook - powder -painted spheroid cast iron.
3. O -ring - EPDM.
4. Guide bracket - stainless steel 304.
5. Screws, pads, nuts - stainless steel 304.
6. Anchors - stainless steel 304.
7. Fischery - plastic / stainless steel 304.
