PSW8-A internal sewage pumping station DN800-400-640 liters

PSW8 is an internal sewage pumping station designed to service single and multi -family houses and small companies. Version A is adapted to free -standing pumps at the bottom of the tank. The simple design allows the pumping station to be adjusted Em4is psw8 to very diverse installation conditions.

Advantages:

• Small dimensions - PSW8 is a DN800 tank, i.e. a diameter of 800 mm inside.
• The tank is covered with a pehd cover that protects against leakage and escaping vapors.
• The direction of the inlet and outlet is adapted individually to the client's needs and building capabilities. This makes it easier to install and adapt to existing conditions at the construction site.
• The whole equipment of the pumping station is made of highly corrosion -resistant materials and aggressive wastewater: pipes and PE connectors, a shut -off ball valve, nipples, a chain, skecters and stainless steel screws, a ball check valve made of powder -painted cast iron.
• The set includes loose PVC 50 and PVC 110/PVC 160 seals for self -making and ventilation holes.
• All components are trade elements that can be replaced (serviced) in the event of wear or damage). They are not dependent on one supplier, who then dictates prices.
• For the pumping station you can use the pump and control of almost any manufacturer, just determine with us the diameter of the pump connection and the type of control to avoid surprise during installation.
• The pumping station can be used to pump sewage with faeces, light sews (shower, washing machine, sink) or for pumping rainwater. It all depends on the selected type of pumps and control.
• The flexibility of the project allows the use of ball check valves inside or outside the tank, depending on the availability and space around the tank. Shut -off valves Always We place outside.

PSW8-A internal sewage pumping station includes:

1. PEHD tank with an internal diameter Ø800 and height You can choose from the list.
2. Discharge department (1 or 2) with a diameter to choose from the list,
3. Ball check valves (quantity in accordance with the number of pumps)
4. Shut -off ball valves (quantity in accordance with the number of pumps)
5. A rubber EPDM gasket for PVC 110 or PVC 160 pipe (select when ordering).
6. Rubber seals for PVC 50 pipe for ventilation and pump supply cables and/or swimmers - 2 pcs.

Example of marking:

PSW8-501A09 - DN800 tank, vertical and outlet DN50, version A (free -standing pump), tank height ~ 900 mm.

The pumping station does not contain pumps or controls that should be purchased separately.

If the selected configuration is not available immediately, the delivery time is about 10 business days.

Free delivery !!!

It is also possible to order installations, connect, start and train service. Ask!
