Metalchem-Warsaw
Metalchem-Warsaw S.A. This is a Polish manufacturer of environmental pumps and devices with many years of tradition. Already in the mid-1980s, based on its own constructions, the company began the production of specialist pumps, including descendial sewage. The breakthrough moment for the company was the implementation and launch of the production of submersible pumps in cooperation with the Finnish company Sarlin. Since then, based on your own construction office, their own construction solutions have been created, and other devices related to environmental protection have been created.
The plant has its own construction office, in which a group of specialists professionally selects devices and designs solutions for the individual needs of clients. The plant has its own processing halls, where we prepare parts for pump and pumping stations, as well as assembly halls, warehouses and a trade office.
Pump code designation:
| Ms | V | – | 80 | – | 22 | 4 | H | – | WITH* |
| 1 | 2 | 3 | 4 | 5 | 6 | 7 |
- SPECIAL PUMP METALCHEM-WARSZAWA SPÓŁKA AKCYJNA.
- Rotor type:
- V - Vortex, an open rotor with a free flight under the shoulder blades,
- K1 - channel, closed rotor with one channel,
- K2 - Channel, a closed rotor with two channels.
- Free flight of balls with a diameter in millimeters (under an open rotor or through a channel in a closed rotor), not available in a version with a shredder. Markings: 15, 50, 80, 90, 100 and R - shredder.
- Engine power in KW (excluding decimal places).
- The number of engine poles (indicates the rotational speed: ~ 2900, ~ 1450, ~ 900, ~ 700).
- Pump lifting height at a given power:
- L - short,
- M - mean
- H - tall,
- No symbol means that there is only one version of the pump.
- * Optional version designation:
- WITH - with a hook (for mounting on the clutch knee),
- P - with a flexible hose connection,
- S - on a stand,
- K - with a basket
Example of marking MSV-80-124L-Z Specific pump with a rotor Vortex, free flight 80 mm under the rotor, 12,5 kw, 4 -To -run engine, low Lifting, with a clutching hook on the clutch knee.
